Khoom Taw qhia
SQ 508 zinc plated ceev txuas
HOMAR's SQ 508 zinc plated Quick Link yog cov khoom siv zoo ua los ntawm cov khoom siv hlau tsis muaj steel. Cov connector no yog galvanized los xyuas kom meej ib tug du nto thiab durability. Lub SQ 508 zinc plated Quick Link muaj qhov zoo nkauj heev thiab yog ua los ntawm cov khoom siv zoo stainless hlau uas tuaj yeem tiv taus qhov hnyav.
Kev siv ntau yam:
Qhov linker no muaj ntau yam thiab haum rau ntau yam kev siv sib txawv. Nws tuaj yeem siv rau kev ua kis las thiab kev ua si sab nraum zoov, xws li pob zeb nce toj, caij skiing, mus pw hav zoov, thiab lwm yam. Nws kuj tseem siv tau rau cov hom phiaj hauv tsev, xws li nuv hauv chav ua noj lossis chav dej, lossis rau txoj hlua los tuav qee yam khoom.
Yooj yim rau siv:
SQ 508 zinc plating ceev txuas yog yooj yim heev rau siv. Tsuas yog nias lub khawm maj mam qhib qhov txuas thiab tom qab ntawd txuas mus rau qhov khoom xav tau. Tsis muaj cov cuab yeej lossis cov txuj ci tshwj xeeb xav tau. Ntxiv mus, lub connector kuj tau yooj yim tshem tawm kom rov siv dua.
Cov ntaub ntawv ceev saib ua ntej
| Hom | HOMAR |
|---|---|
| Xim | Nyiaj |
| Hom tiav | Zinc plated |
| Khoom siv | Stainless hlau |
| Duab ntxoov ntxoo | Stainless hlau |
| Yam khoom naj npawb | SQ-508 |
| Ua kom tiav | Zinc plated |
Parameter specification cov ntaub ntawv
|
Loj mm |
A mm |
B mm |
C mm |
D mm |
L1 mm |
L mm |
W.L.L lbs |
N.W g/pcs |
| 3.5 | 17 | 10 | 5 | 3.5 | 29 | 39 | 200 | 8 |
| 4 | 19.5 | 11.5 | 5.5 | 4 | 31.5 | 39.5 | 440 | 12 |
| 5 | 23 | 13 | 6.5 | 5 | 38.5 | 48.5 | 660 | 21 |
| 6 | 26.5 | 14.5 | 7.5 | 6 | 45 | 57 | 880 | 35 |
| 7 | 30 | 16 | 8.5 | 7 | 52 | 66 | 1200 | 54 |
| 8 | 33.5 | 17.5 | 10.5 | 8 | 58 | 74 | 1500 | 75 |
| 9 | 37 | 19 | 11 | 9 | 62 | 80 | 2000 | 105 |
| 10 | 40.5 | 20.5 | 12 | 10 | 69 | 89 | 2400 | 135 |
| 12 | 47.5 | 23.5 | 15 | 12 | 80.5 | 104.5 | 3300 | 228 |
| 14 | 54.5 | 26.5 | 17 | 14 | 93 | 121 | 4800 | 350 |
| 16 | 61.5 | 29.5 | 19 | 16 | 108 | 140 | 6400 | 500 |
SQ 508 zinc plated ceev txuas advantgae
(1) Kev sib txuas ceev yog ua los ntawm cov hlau tsis muaj steel, nrog zoo corrosion kuj thiab siab hardness.
(2) Galvanized thiab polishing kev kho mob ua rau saum npoo ntawm qhov txuas ceev nrawm thiab cov ntug burr dawb. Cov txheej txheem ntawm galvanizing cov kev sib txuas muab cov txheej txheem tiv thaiv kev ya raws, xeb thiab corrosion.
(3) SQ 508 galvanized ceev txuas yog ib qho yooj yim mus use, ua tsaug rau nws ceev txuas tsim. Tsuas yog ntxig ob qhov kawg ntawm kev sib txuas ua ke thiab koj zoo mus. Koj tuaj yeem siv nws rau ntau yam kev siv, suav nrog kev ruaj ntseg cov khoom siv mus pw hav zoov, txuas chains lossis txuas hlua thiab cables.
Cim npe nrov: zinc plated ceev txuas, Tuam Tshoj zinc plated ceev txuas manufacturers, lwm tus neeg
